Morley-IAS Lite addressable Fire panel supporting up to 159 addressable devices and communication capabilities

LT-159

LT-159 control panels include Honeywell's Advanced protocol which maximizes the speed and efficiency of alarm detection, as well as providing maximum information to the installer. The 4.3" (480x272 pixel) Touch Screen provides an intuitive user interface via its menus with quick and easy system operation. The LT-159 Series control panels allow configuration from the screen itself and a maximum of 159 addressable devices in the system.

• Includes 6 AA-size 2,800mAh nickel metal hydride (Ni-MH) batteries
• Language selection, available in English, Italian, Spanish Arabic, Portuguese, Romanian, Dutch, French, Turkish, Albanian, Slovenian, Serbian, Croatian, Greek, Bulgarian, German
• Quick configuration of the unit from the same display
• Certified to EN54-2:1997+A1:2006 and EN54-4:1997+A1:2002 and A2:2006; LVD 62.368-1:2014+A11
Main power supply
230 V AC +/- 15%, 50 / 60 Hz
Power consumption
max. 24W
Battery capacity
6x AA size 2.800 mAh
Outputs
1 fault (NO/NC); 1 alarm (NO/NC)
Sounder output
1, max. 50 mA
Color
RAL 7021/9005
Protection class
IP30
Dimensions (H x W x D)
126.9 x 206.9 x 42.7 mm
Operating temperature
-5 °C to +40 °C
Humidity
5% - 95% non-condensing
Weight
400 g
