ESSER by Honeywell Conventional Panel with 4 Zones

ESS4-2PLUS

The ESS4-2Plus control panel is designed to adapt to the strictest requirements regarding the control of conventional fire detection systems, giving priority to the ease of use, the reliability and high local or remote control performance.
The control panel has a graphic 4,3” TFT touch screen, for indication of status, voltages, configuration and event log. It is possible to configure a drawing or image by zone, in order to obtain a precise and graphic indication in case of alarm. It also has integrated memory in the display to store the event log and graphical configuration maps.

The ESS4-2Plus control panel includes two communication ports for integration (e.g. in the TG graphic management software) and a bus for I2C modules. 2 serial port modules, 3 modules of 4 relays and bidirectional and remote communicators can be connected to the control panel to be integrated into the Esser by Honeywell analogue loop. The control panel can support any device from the conventional range of Esser by Honeywell ES detect and most manufacturers.

Features & Benefits
Technical Data
Accessories
Documents

• Fast and secure installation
• Input monitoring (Resistive RFL/Capacitive EOL)
• Alarm verification in zones
• Detector/Call point identification
• Activation of relays or sounders by 2 zone coincidence.
• Earth leakage fault sensitivity
• Universal power supply
• Remote communication options and full remote control

Power supply	120/230 Vac ±15%; 50/60 Hz.
Total max. current	2.4 A
Batterv charging voltage	27.3V at 20°C
Battery load current	300 mA max
Battery fuse	F4AL 250 V (5 x 20mm)
2 monitored sounder outputs	2 x 500 mA
2 aux. power supply outputs	18,5 - 28.5Vdc (24Vdc nominal) / 2 x 250 mA (resettable and non-resettable)
Operating temperature	-5 °C to +45 °C
Operating humidity	95% max. RH
Panel sealing	IP30
Dimensions	W: 380 mm H: 350 mm D: 125 mm
Weight (without batteries)	4 Kg
Plug-in Terminals	2,5 mm2 max.
Housing Colour	RAL 7021
Material	ABS V0

NFS-TFT TFT 4.3" CONV.PANEL 4-12Z SUPRA/2Plus
VSN-4REL FIRE PANEL ADR/ABLE Relay Card
VSN-232 FIRE PANEL ADR/ABLE RS 232 I/Face
TG-IP1-SEC INTERFACE RS232/485 TO IP 10/100MHZ
TG-BASE Dongle with TG w/o license
TG-C GRAPHIC SOFT License for conventional panels RP1r, VSN-2Plus
